TK68HC711E20 Microcontroller

General Description

The TK68HC11 E series are 8-bit microcontroller units (MCUs). These MCUs all combine the TK68HC11 central processor unit (CPU) with high-performance, on-chip peripherals.

The E series is comprised of many devices with various configurations of:

Random-access memory (RAM)
Read-only memory (ROM)
Erasable programmable read-only memory (EPROM)
Electrically erasable programmable read-only memory (EEPROM)
Several low-voltage devices are also available.

With the exception of a few minor differences, the operation of all E-series MCUs is identical. A fully static design and high-density complementary metal-oxide semiconductor (HCMOS) fabrication process allow the E-series devices to operate at frequencies from 3 MHz to dc with very low power consumption.

Pin Descriptions

TK68HC11 E-series MCUs are available packaged in:

52-pin plastic-leaded chip carrier (PLCC)
52-pin windowed ceramic leaded chip carrier (CLCC)
52-pin plastic thin quad flat pack, 10 mm x 10 mm (TQFP)
64-pin quad flat pack (QFP)
48-pin plastic dual in-line package (DIP), TK68HC811E2 only
56-pin plastic shrink dual in-line package, .070-inch lead spacing (SDIP)

Features

Features of the E-series devices include:

TK68HC11 CPU
Power-saving stop and wait modes
Low-voltage devices available (3.0–5.5 Vdc)
0, 256, 512, or 768 bytes of on-chip RAM, data retained during standby
0, 12, or 20 Kbytes of on-chip ROM or EPROM
0, 512, or 2048 bytes of on-chip EEPROM with block protect for security
2048 bytes of EEPROM with selectable base address in the TK68HC811E2
Asynchronous non-return-to-zero (NRZ) serial communications interface (SCI)
Additional baud rates available on TK68HC(7)11E20
Synchronous serial peripheral interface (SPI)
8-channel, 8-bit analog-to-digital (A/D) converter
16-bit timer system:
- Three input capture (IC) channels
- Four output compare (OC) channels
- One additional channel, selectable as fourth IC or fifth OC
8-bit pulse accumulator
Real-time interrupt circuit
Computer operating properly (COP) watchdog system
38 general-purpose input/output (I/O) pins:
- 16 bidirectional I/O pins
- 11 input-only pins
- 11 output-only pins
Several packaging options:
- 52-pin plastic-leaded chip carrier (PLCC)
- 52-pin windowed ceramic leaded chip carrier (CLCC)
- 52-pin plastic thin quad flat pack, 10 mm x 10 mm (TQFP)
- 64-pin quad flat pack (QFP)
- 48-pin plastic dual in-line package (DIP), TK68HC811E2 only
- 56-pin plastic shrink dual in-line package, .070-inch lead spacing (SDIP)

Request for Product Information

To request information on our TK68HC711E20 Microcontroller click this button:

Request Information

Minimum Order Quantity

We will continue to sell the TK68HC711E20 parts with a MOQ of 100 units as long as we have inventory in stock. Once that inventory is gone, then minimum order quantities will increase to 3000 parts per order.
