TK68020 Microprocessor
General Description
The TK68020 is a functional equivalent of the Motorola M68020 and they are pin-for-pin compatible. It is a full 32-bit implementation of the M68000 family of microprocessors from Motorola.
The TK68020 is a full 32-bit implementation of the 68000 family of microprocessors from Motorola. The TK68020 is implemented with 32-bit registers and data paths, 32-bit addresses, a rich instruction set, and versatile addressing modes.
The TK68020 is object-code compatible with earlier members of the 68000 family and has the added features of new addressing modes in support of high-level languages, an on-chip instruction cache, and a flexible coprocessor interface with full IEEE floating-point support available. The internal operations of this microprocessor operate in parallel, allowing multiple instructions to be executed concurrently.
The asynchronous bus structure of the TK68020 uses a non-multiplexed bus with 32 bits of address and 32 bits of data. The processor supports a dynamic bus sizing mechanism that allows the processor to transfer operands to or from external devices while automatically determining device port size on a cycle-by-cycle basis. The dynamic bus interface allows access to devices of differing data bus widths, in addition to eliminating all data alignment restrictions.
Features
|
Request for Product Information
To request information on our TK68020 Microprocessor click this button:
Minimum Order Quantity
We will continue to sell the TK68020 parts with a MOQ of 100 units as long as we have inventory in stock. Once that inventory is gone, then minimum order quantities will increase to 3000 parts per order.
Documentation
The data sheet is available here: TK68020
